19" Series 395 Channel Balance

Product Code: S395-19

Product Description
This series 395 channel balance also known as a block and tackle balance has a 19" long metal channel and is for a non tilt window. The channel's width measures 9/16" but is considered 1/2" in the trade. This balance comes fully assembled with a 15-001 shoe and a 19-005 top attached.
Stamp Option Sash Weight Range
1810 5 to 8 lbs
1820 8 to 12 lbs
1830 12 to 14 lbs
1840 14 to 17 lbs
1850 17 to 20 lbs
*This information is based on 2 balances per sash. Balances are designed assuming friction in the jamb weather-strip will carry a portion of the sash weight. Suggested sash weights are approximate.
