39" Series 395 Channel Balance

Product Code: S395-39

Product Description
This series 395 non tilt window channel balance has a 39" long metal channel. The channel's width measures 9/16" but is considered 1/2" in the trade. This balance comes fully assembled with a 15-001 shoe and a 19-005 top attached.
Stamp Option Sash Weight Range
3810 9 to 14 lbs
3820 14 to 19 lbs
3830 19 to 24 lbs
3840 24 to 30 lbs
*This information is based on 2 balances per sash. Balances are designed assuming friction in the jamb weather-strip will carry a portion of the sash weight. Suggested sash weights are approximate.
