Measurements of the deadbolt

Handy Person
Sep 13, 2009 1:02 pm
I need to know the measurement of how far the 40-155 deadbolt sticks out from the door facing in. I have a doorknob on my inside door and want to know if the deadbolt will fit on my storm without hitting the doorknob.
5 Replies
Dave Sr.
Dave Sr. from SWISCO
Sep 14, 2009 8:26 am
SWISCO
EXPERT
The inside thumb turn sticks out 1 1/4" toward the inside. If this is too close to your inside door try installing it above or below your inside door handle and hardware.
Handy Person
Sep 14, 2009 5:56 pm
Do you make a deadbolt that sticks out less than 1 1/4" from the storm door?
Dave Sr.
Dave Sr. from SWISCO
Sep 16, 2009 6:23 am
SWISCO
EXPERT
Sorry, we do not have one that sticks out less than 1-1/4". I do not believe any one would have it because you need the height for the mechanism of the deadbolt and thumb turn.
Home Owner from South Carolina
Feb 9, 2010 11:00 am
What are the dimensons of the part of the dead bolt on the inside of the door? The storm door that I have is a full glass door with a narrow frame.
Paul
Paul from SWISCO
Feb 11, 2010 6:16 am
SWISCO
EXPERT

The deadbolt of the 40-155 lock set is 1-1/4" wide. I included a picture of the deadbolt with measurements. Let me know if you need anymore measurements.

Detail of outside lock 40-155
Detail of outside lock 40-155
