Channel Balance ID

Home Owner from Cape Coral, Florida
Springs are rusty and don't snap back. Metal is 17". Window weighs 6 lbs. Markings are faint but seem to be: DB HO1 16-1

Can you send link to purchase 2?
4 user uploaded images
2 Replies
Lauren
Lauren from SWISCO
SWISCO
Expert

Hello, thank you for posting,

With this combination of attachments, you could have either an S380 or S385 channel balance. You’ll need to measure as shown below. The Series 380 has a 1" bottom attachment, and the Series 385 has a 1-3/32" attachment. You will need a 17" balance with a 1610 stamp option.

Please review and let us know if you have any additional questions!

Comparison of the S378, S380 and S385 balance shoes.
Comparison of the S378, S380 and S385 balance shoes.
