Shower door sweeps

Home Owner from USA
Sep 29, 2015 4:02 pm

Can I use a frameless shower door sweep like 10-328 or 10-331 depending on glass/door frame size to replace a shower door sweep like one that like 10-324, 10-325 or 10-326? The frameless sweeps look/seem so much better and appear easier to install.

I appreciate your help and look forward to the information!

Kindly contact me with any questions. Thank you.


John F
3 Replies
Tom from SWISCO
Sep 30, 2015 1:40 pm
It would depend on the size of your glass. The 10-328 is used for 1/4" thick glass. The 10-324, 10-325, and 10-326 likely won't work for your frameless door since you need to drill out installation holes for them.
Quick Learner from FL
Sep 30, 2015 5:09 pm
I asked my question incorrectly. I am trying to replace a door sweep on a framed shower door. Would either a frameless shower door sweep like 10-328 or 10-331 fit and work on a framed shower door?

If not, would you suggest either a 10-324, 10-325 or 10-326 depending on the framed shower door length?

My current shower door does not have screws. Would a 10-324, 10-325 or 10-326 be easy to install if I had to drill holes? Do screws come with the door sweeps? If not, what size screw should I buy?

I look forward to your reply. Thanks again!


John F
Dave Sr.
Dave Sr. from SWISCO
Oct 2, 2015 10:24 am
Thank you for clarifying. You might be able to use one of the frameless sweeps, but then it would depend on the thickness of the frame. If you do have a metal frame door I honestly believe a screw-on type would be the better choice.

In terms of installation hardware, our 33-071 set screw would be what I recommend. You will need to use a 7/64" drill bit to make the holes in the door frame. Take note and be careful you do not drill into the glass or damage the door when drilling. You might want to get a professional to help with the installation. With this in mind, I can understand why you might want the easier installation of a frameless sweep, but it may simply not be big enough to work on your door.
