Tilt Latch

Quick Learner from NJ
Jun 4, 2020 1:53 pm
Hi need new tilt lathes to replace several broken ones on opposite sides of some windows. Please let me know if you have these parts and instructions on how to replace. Thanks!
IMG_3511 IMG_3512 IMG_3513 IMG_3528 IMG_3529
5 user uploaded images
3 Replies
Tom
Tom from SWISCO
Jun 9, 2020 10:30 am
SWISCO
EXPERT

I believe we can help, yes! Please see our 26-408 tilt latch pair. I believe this is just the part you're looking for, but you should still review our dimensions to confirm.

Quick Learner from NJ
Jun 14, 2020 11:17 pm
Thanks. I just placed an order.

Can you please provide me with directions on how to safely take the old ones out and put these new ones in?

Or do you provide a video as well?

Thanks!
Dave Sr.
Dave Sr. from SWISCO
Jun 15, 2020 11:27 am
SWISCO
EXPERT

Hey there, I think I can help. I do agree that the 26-408 is the tilt latch you need for your Silverline brand window. The reason I'm stepping in is because I just recently replaced a set myself.

You will need to first install the front "nose" into the the cut out at the top side of the sash. You just slip it in from the top. Then, once it's in, push the back end into the cut out at the top until it "snaps" in place.

Take note that I had to file down the flat side of the "nose" to make it slide easily. It was a little difficult otherwise. That may not be necessary in your case, but I thought I'd mention it just in case you ran into the same issue.
