Bifold door

Home Owner from USA
Hello,
I have some old metal bifold doors. I'm looking for everything in the picture and the doors look pretty much like this.

But I mostly need the stuff for the top. Everything basically including the plastic piece that goes into the track that sits on the pin.
3 user uploaded images
6 Replies
Casey
Casey from SWISCO
SWISCO
Expert

Hello,

I don't recognize this bifold pin at first glance but I'm going to have one of our senior experts take a look and see if they could recommend a replacement for you. We'll reach out as soon as more information is available. Thank you!

Handy Person from USA
Ok thanks
Paul
Paul from SWISCO
SWISCO
Expert

You are showing old-style Slimfold doors. Slimfold has made some changes but the new style pins will still work on the old doors. You'll need one 21-001 bottom corner adjusting pin. The 21-001 pin uses a pivot rod clamp like the 21-154. The other three pins will be the 21-007, one for the top pivot and the other two for the top and bottom guide pins. There is no need for rod clamps for these pins. The pivot bracket will be the 21-200. All the door adjustment is done by the 21-001 bottom pivot pin to square up and operate the door. Review the related guides for more information.

Handy Person from USA
Here's a pic of the label on the door just to confirm that the parts are correct.
1 user uploaded image
Paul
Paul from SWISCO
SWISCO
Expert

Unforutnately, the label does not give us any new information but the parts I mentioned previously would be our best recommendations. Just make sure to compare the specifications on our product pages to yours.
