Cast aluminum door slide bar

Quick Learner from Godfrey, Illinois 62035
After washing the window, it evidently was slightly out of alignment and broke I broke the pictured piece while forcing the window closed. What is the part called / part number, is it available, and is it hard to install?

Is there a right and left hand? The piece which broke is on the left side when looking at the window from the inside.

Help me if you can. Thanks Rick
User submitted photos of a pivot bar.
4 Replies
Tom
Tom from SWISCO
SWISCO
Expert
Hey, Rick. Looks like you have an old Certainteed pivot bar. They discontinued this style and replaced it with the 26-175. I know it looks different, but it should still work with your existing pivot shoe, assuming your old pivot bar is Certainteed. Let me know your thoughts.
Quick Learner from Godfrey, IL
Thanks for your prompt response. Looks like the pins come in pairs with a right and left, Correct?
Tom
Tom from SWISCO
SWISCO
Expert
Yep, that's correct.
