Folding crank for window treatment
Quick Learner from Window blind
Feb 25, 2023 11:55 am
Would the shorter crank or folding crank work with this fixture, I want to install window treatment
2 user uploaded images
6 Replies
Lauren from SWISCO
Feb 27, 2023 12:27 pm
Hello, thank you for posting,
It appears that your window uses Andersen hardware. The best we can provide is the 39-301 folding handle or 39-298 T crank that both fit onto a 3/8" diameter operator spline size. Please note that these styles will not provide full clearance for blind applications. Let us know if you have any additional questions.
Quick Learner from Window blind
Feb 27, 2023 1:52 pm
how far out would the crank be? and doesn't the folding crank fold? Isn't doesn't look like there is a photo of the folding handle, folded?
thank you
thank you
Lauren from SWISCO
Feb 28, 2023 10:22 am
Hello,
The picture below is the 39-301 handle flat. It has a 1-3/16" projection as outlined with the red line.
Quick Learner from Maryland
Mar 12, 2023 5:19 pm
Which of these options would provide more clearance in this application?
Tom from SWISCO
Mar 13, 2023 1:14 pm
I would say that the 39-298 T handle provides the most clearance. Just keep in mind that no matter how low a handle can fold, it can't go any lower than the operator stem. That's a fixed part of the mechanism and nothing on the market can allow an operator to sit lower than that.
