Top portion that makes a "replica" of glazing putty between window frame and glass is at about 30 - 45 degree angle from "snap in spline". The top of this section measures 7/16" wide.
The spline runs down the center of the piece and this is what inserts into the window frame to hold the glass against the frame with the top making the "glazing seal". The length/depth of the spline leg is 5/16".
The last picture shows it in the position of the bead when inserted into the window frame.
Appreciate any assistance you can offer?
Plastic glazing bead - ranch style window (no markings or method of ID)
Home Owner from Stillwater, MN
Sep 7, 2023 3:05 pm
5 user uploaded images
2 Replies
Emily from SWISCO
Sep 8, 2023 11:29 am
Hello there!
I'm afraid this isn't a style we're immediately familiar with. It may just be the angle. Could you show some clearer photos of the end profile from a few different angles?
