Replacement mortise set : SWISCO.com

Home Owner from Okemos, Michigan

Jul 15, 2023 2:50 pm

Attached photos of storm door installed @ 1990-2000
Neighbors have similar doors which they claim were purchased at Home Depot. No markings or ID found on door or frame.

Any ideas for a replacement set?

4 user uploaded images

8 Replies

Bob from SWISCO

Jul 15, 2023 4:20 pm

Thanks for posting. How does our 40-049 Storm Door Lockset compare? Review the diagrams below and let us know if anything differs.

alternate view of 40-049

Dimensions for 40-049

Home Owner from Okemos, Michigan

Jul 16, 2023 7:57 am

Thank You. All the dimensions on the "alternate view" diagram match except the handle on my door is in the lower position, and the locking mechanism is in the upper position

1 user uploaded image

Bob from SWISCO

Jul 16, 2023 11:27 am

Thanks for getting back to me. It looks to me that the mortise lock is also 'inverted' in your door compared to our diagram, is that not so? If correct, then I don't think there should be any issue, you would just need to install the 40-049 'upside down' compared to how we present it. We do see this from time to time, and typically installing the handle set upside down doesn't affect performance. Let me know if you have further questions.

Home Owner from Okemos, Michigan

Jul 16, 2023 11:40 am

Thanks Bob. I will give it a try.

Bob from SWISCO

Jul 16, 2023 12:30 pm

Sounds good. Let us know how you make out, and thanks again for reaching out.

Home Owner from Okemos, Michigan

Jul 25, 2023 4:08 pm

Thanks for all your help.

Everything fits and functions properly!

Bob from SWISCO

Jul 26, 2023 9:17 am

That's great news! Thanks so much for the update, I'm sure this information will help other customers in the future.

As always, please feel free to contact us for assistance with any future projects.
