Sweep difference between 90-005 or 90-009? 90-086?

A home owner from Lake County, Ca says:
December 21, 2011
I ordered the 90-005 to replace Allenco hardware but the sweep is a bit too thick, is the sweep thicker or thinner on the 90-009? How about the 90-086? Any suggestions?
Profile picture of Tom
Tom from SWISCO responded:
December 22, 2011
Thanks for posting!

I put together an alternate view of each lock, the 90-005, 90-009 and 90-086, comparing their "sweep thickness."

See below for details:
Latch thickness of 90-009 Window Lock.
Latch thickness of 90-009 Window Lock.
Latch thickness of 90-005 Window Lock.
Latch thickness of 90-089 Window Lock.

Do you happen to have any measurements of your existing lock, or any pictures you could share with us? Let me know if you need any additional measurements for any of these locks or any other hardware.
A quick learner from Lake County, CA says:
December 22, 2011
I will see if I have a whole one I can compare to the 005 as I only tried it on one window. Perhaps the sweep is the same, If it is actually narrower, as I believe I will photograph them side by side for your review. The house was built in 97' I believe and the sweep locks all say Allenco.
Window Lock, 2-1/4"
Window Lock, 2-1/4"
90-009
$2.32
Window Sash Lock, 2-1/4"
Window Sash Lock, 2-1/4"
90-005
$2.05
Window Lock, 2-1/4"
Window Lock, 2-1/4"
90-086
$4.07
