pivot lock shoe

Hey Mike. Check out our 15-178 or 15-188 Pivot Shoes. One of these might be the replacements you need, but look over the thickness to see which is the closer match.

I believe I can help. Unfortunately, your narrow version pivot shoe has been discontinued. We do have a replacement option, but you'll have to replace the channel balance as well as the shoe. We suggest using the S795-23; not that we've added one inch to your original balance's length to compensate for the old pivot shoe height. You will need to purchase the 15-194 1" T-Lock Shoe, sold separately. You can swap this shoe with the one that comes installed by default with this balance; it's an easy process, as the video below demonstrates. Finally, I believe you need a stamp option of 23B, for a sash weighing between 10 through 16 lbs. You'll also need a new pivot bar I think, so compare your old one to either the 26-021 or 26-241.
