Alside Vinyl Windows from 2004 - Need pivot bar replacement and lock shoe

Thanks for reaching out! The shoe in this assembly appears to be the 15-177 Coil Balance Shoe. To confirm that this is the correct replacement, carefully review and compare the dimensions.

The pivot bars can most likely to be replaced with the 26-226 Pivot Bar.

Alternate image for 15-177

End view of the 26-226 pivot bar

The coil springs compatible with this shoe is the Series 152 Coil Balance, attached using the 33-072 screw. To determine the correct coil weight option, you'll need to look for a stamp/marking on the spring. If there isn't one, please see the video tutorial below for instructions on how to choose the spring.

If you can reuse the existing covers, that would be suggested. Otherwise, the 15-143, 15-144, and 15-145 can be used to replace them.
