American craftsman tilt out window model number 2127 single hung

Thanks for reaching out! The pivot shoe you have pictured here looks like our 15-228. Look over the dimensions and compare them to your shoe to confirm that this is the right replacement.

Dimensions for 15-228

These shoes are compatible with the 1/2" wide, Series 160 coil springs. To determine which spring you need, check the metal coils for any stamps. If there are non stamps, you'll need to divide the exact window weight by the total number of coils in the window. The compatible coil spring cover is part 15-150D.
