Double Hung Window Sash Pivot Pin Replacement

Question

Looking to locate replacement part for window due to pivot pins breaking. Pin is 2-1/2" long with hole 2" from T-head. Offset in piece is 7/16". Can find similar straight replacement pins but none with an offset. I have 18 similar windows and looking to purchase replacement pins for all. Not certain if having a straight pin will allow for window to close and latch properly. When installed in the window, short end of the offset (extending from window) to slide hardware higher than the portion installed in the window.

Bob · Accepted Answer

I am afraid we don't have an exact match for this pivot bar, mostly due to that offset. However, we have often found with pivot bars that the offset really isn't that important, so a replacement pivot bar doesn't necessarily need it to work. Thus, I want you to look at our 26-272, 26-378, or 26-448. Look over their dimensions and see if you think any of these options match, especially the shape of the pin that fits into the pivot shoe in the window jamb, and the distance between that pin and the center of at least one mounting hole.
