Need window parts

A home owner from Cedar Rapids Iowa says:
Hello, can you please tell me if available what i halve circled around?
Thumbnail of the uploaded file named C6B0CC37-2A03-4206-9D7D-45D97CF3ED41.jpeg
Thumbnail of the uploaded file named E8815095-4274-49A0-9910-38DB4041AB27.jpeg
Thumbnail of the uploaded file named 4C9998B8-0E15-4BDD-A795-C26761A2349C.jpeg
Profile picture of Bob
Bob from SWISCO responded:

Many thanks for writing in. I am going to approach this with what you have in each picture:

  • The Pivot Shoe in your first picture looks a Caldwell Coil Balance System. Our 15-251 with the Series 160 Coil Springs should work as a replacement.
  • I don't believe the pivot shoe in your second and fourth picture is made any longer, but the 15-046 should work as a replacement.
  • The Pivot Bar in your third picture is probably our 26-083 . Look it over to see if it matches. The screw would be the 33-074 that goes into the nylon housings, the 26-236 and 26-237 .
  • Finally, in your fifth picture you show some weatherstripping. You might need the 58-171 , 58-182 , or 58-183 . Look over the dimensions of all three to see if one matches what you need.
