Window coil replacement

Thanks for reaching out to us! This balance shoe appears to be part of an older Vinylmax coil assembly. We cannot provide an exact replacement match for it but the 15-177 Coil Balance Shoe will work in its place. Be sure to compare the dimensions to confirm.

Alternate image for 15-177

You'll need the Series 152 Coil Balance, attached to the shoe using the 33-072 screw, to replace the springs. For instructions on selecting the correct coil weight option, take a look at the video tutorial below.

You'll need the 15-143 Coil Bushing, 15-144 Coil Bushing Cap, and 15-145 Coil Support Barrel.
