double hung window spring and pivot bar

Question

From Label
Manufacturer Code:MTL-1, Series 3540
H-LC25 - 48 X 78
H-LC30 48 x 72
I need a spring and a pivot bar for the window. I am happy to buy a minimum of 4 springs. I need only one pivot bar

Bob · Accepted Answer

Thanks for posting. This looks like the 15-180 Pivot Shoe, which works with the Series 190 Coil Balance springs. See the guide below that shows how to select spring weights for the replacement coil springs. Let me know if you have further questions.

For the pivot bar, see if either the 26-040 or 26-083 match what you have.

Dimensions for 26-040

Detail of 26-083
