Window doesn't stay up on its own.

Question

The coil balance parts are broken on the first window and not keeping the window up.  These need to be replaced.

Jasmine · Accepted Answer

Thanks for writing in! Your pivot shoe reminds me of the 17/32" thick 15-199 Pivot Shoe. I'm confident it should be a match but be sure to double check the dimensions.

It is used with the 26-378 Pivot Bar.

Alternate view of 15-199

The coil balance support seems to be a match for the 15-205 Coil Triple Support. It is compatible with the 3/8" wide Series 165 Coil Balance. To confirm the right springs for the assembly, you'll need to look for a stamp/marking on them.

If they do not have stamps/markings, please see the tutorial below for instructions on selecting the correct coil weight options.
