Viewing all customer Discussions for:

39-394 LH 10" Hinge Arm Assembly, Pella

Hello. I'm looking for this hardware. We ordered the 39-395 and 39-394 from you, and the piece that attaches to the window is 7". The original we have in the picture is 8 3/16. Do you sell the 8 3/16??

Do you Pella window casement hinge

I have both LH and RH opening windows that need complete hardware replacement. (Both open in opposite directions.) Looking for new opener hinges as well as the crank mechanism and the handle for each. One of the photos has approximate dimensions. I haven't disassembled it and taken pictures yet. ... (cont.)

Please confirm the Swisco replacement crank mechanism for a 1975 Pella wood casement window, 27" x 73". Also need the hinges and lock mechanism

Looking for bottom hinge. Showed part from other window. 2 screws to attach. If set is required, OK.

Need help finding this

Recently when I went to close this window it would not close all the way and the inside bottom corner seems to be missing a part. Attached Thank you for your assistance.Cheryl

Trying to identify which company this bottom operating arm off of a casement window has came from. I am guessing pella, but I am unsure

Looking for the replacement hinge on the 1987 period pella casement window. From the inside the hinge is on the right. From the outside the hinge is on the left (Left hinge then?). Thinking it's this part ?: LH 10" Hinge Arm Assembly, Pella Product Code: 39-394 from your website. It's the shoe ... (cont.)

I need a left hand upper hinge assembly for a Pella Proline 3565 left casement window installed in 2004. I have added a photo with measurements.

Need Help identifying window hinge that's broken in window need a 2 count since they are both needed to be replaced

Not sure the manufacturer. But that bottom hinge on this particular model I have never seen !! Can u please help identify

the above armature (with meqasuring tape was fastened to the peice in the other photo to form a "tee" that kept window in algnment as it opened. looking from the inside the window hinges on the right (and opens on the left). I believe the winows are about 30 years old? Thanks for any info. ... (cont.)

I have several pella casement windowsinstalled in New home built in 1989. Most are hanging out of plum while the frames have stayed plum. Lifting up and down while open you can see the white guide at the top is sloppy. Bottom guide stays intake with little movement. The support hindge measures 11 an ... (cont.)

I'm looking for all the operating parts for a pella casement window. I need top and bottom pivot slides, the locking armature, top arm, plastic slides, all parts. I have two windows that have been screwed shut and all parts removed due to rust and age and the owner wants to rebuild them so they op ... (cont.)

pella 9040302 rh hindge

Hi there. after replacing the 39-175 pella hinge on my casement window, I noticed that the upper plate was bent and causing some misalignment. How do I get one of these along with the slide? Thank you.

Looking for replacement part that connects to window and slides on a framed track.

Hello, I have an original pella casement from a 1965 home. The tipe guide that slides along and keeps the window in place has worn out. You can see it in the last image from a top view. The other images show the other components to help identify the model. Is this piece available? ... (cont.)

Hello,Please find attached the photos requested.Thank you so much for your assistance, Mike and TheresaThe first photo is facing down, second photos facing roof, and dimensions are in the third photo.
