Viewing all customer Discussions for:

26-316 Interlocking Pivot Bar

Parts needed

The photo is the right side (looking from the inside) upper glass.l would like to purchase both left and right side bars.

Hi, Looking for a replacement part, I believe it's called a pivot bar, screws into window frame and then attaches for weight and balance on the side. Windgate/Belmont Single Hung Vinyl window. HR50 1118x1600 (44x63) Single Hung DP50 31 1/2 x 61 1/2 Approximately 1.75 inches depending upon where the ... (cont.)

Do you sell a L shaped pin like this one which is held by 2 small screws?

Coil balance series: S140 Sash-weight: 21lb window Coil-stamp: None Quantity: 2 Comments: Mine was a 2 piece coil spring & a separate shoe. I need the double coil. Year 2003 Alliance

I need a corner pivot bar for one of my windows. The track that the pivot bar sits in on the window frame is 5/16 of an inch. The actual pivot bar that inserts into the window track is also 5/16 of an inch. Please see the pictures. Any recommendations? Thank you for your help.

Hi, thanks in advance for the help. Both pivot bars have broke off. I've sent three photos with the little information I have. Please be in touch. Thanks again.

I need two sets (2 left and 2 right) of replacement balance shoes, And 2 replacement pivot pins. I believe these were manufactured by Alliance Window Systems approx 20 years ago. If you have replacement parts, I would like to purchase.

Have several broken pivot bars can you suggest replacement? Alliance window Belmont It looks like it measures about 2" from last screw to tip

The hammer head part broke... need to replace.... window is from homedepot

Looking for these parts.

Hi- I'm looking for these parts that allow the window (Mastic windows I believe) to stay open when lifted. The grey pieces are quite corroded and brittle (the one pictured has fallen apart), and the tan sliding parts are usually worn as well.

I'm I need of the sash pivot. It's held in with three screws. One on the pin face and two below. It slides into the extrusion of the vinyl window.

Hello my name is Greg and I am trying to find 2 of these replacement pieces for the bottom of a tilt wash sash that goes into a coil sash balance system.

Missing the left side from the inside of a Harvey window. Pictures are from the right side of the window. The missing piece fits into a "U" shaped side that goes up and down with the window mechanism.

Shoe is 1 1/4 wide 1 1/2 high 1/2 width Pivot bar I 2 1/4 long between the hole is 3/4 All in inches.

Can you help me find this pivot bar. I thought the 26-316 looked like a candidate. But it looks like the shoulder and head are a little shorter. The total length was a couple of eighths shorter also. Any other suggestions?

This is a replacement window with no name on it The first and 3rd pict are the pivot pin that sits inn the shoe. The 2nd pict is the shoe itself. Can you identify both the type of window pin and shoe?

Hi my parts I ordered were a little to big , is there any other size that you have ?

They are for an unknown brand vinyl double hung window. They have 2 screws that secure them to the bottom of the windows.
