Viewing all customer Discussions for:

15-070 Thermal Gard Pivot Shoe

Hello, Do you have a replacement for this? Thank you

Loving for replacement shoes at this time.

Need to find a replacement pivot shoe for an old window (50-60 years old). Shoe is 1-1/4" wide x 1-3/4" high x 5/8" deep. Cam housing protrudes about 1/8" from the 5/8" depth measurement. Cam appears to be black. Window is 22" x 48" 27lbs. Has two blue spiral balances on each side. measures 1/2" wid ... (cont.)

This rod broke on other side of window

Hello, I,m looking for this pivot lock shoe. It is out of a weather Guard tilt window. I would need approximately 12. Thanks for any help you can provide.

It is 5/8 thick

Is this combo anything your research department is familiar with? From a large older vinyl double hung window.

Which pivot lock shoe do I need for this Jaffe window.? The sash balance is 25" and I'm pretty sure it it 5/8". I included the widow mfr info. Thanks Ted

Should have done this to begin with...I ordered and received the wrong pivot shoe. (15-070) Looking for your help to get the correct one. The image in my hand is what remains of the broken one. Other images are to help identify windows. I measured it at 1 1/4in wide, 2in deep, I think 2 inches tall ... (cont.)

Hi,I need to purchase Pivot Bar Sets and pivot shoes for an older thermal guard window.please provide the replacement or compatible parts number based on the attached pics. thanks,Rafael

Hi, I have thermal gard windows, they aren't staying up. I found that few pivot shoe are broken. I'm thinking to replace the whole hardware to make it right at once. I'm not sure what parts do i need so I'm attaching pictures for your expert opinion. Also the measurement for spiral balance is 22 in ... (cont.)

Please help me identify this part measures 3/4 thick1 1/4 wide2 1/4 high

Hi, Help, bought pivot shoe and it seems to be the correct thickness but needs an additional button on the black disc. The window can't lock in.

We bought 12 Thermal Gard pivot shoes 15-070 after somebody on Swisco suggested it. We watched the video and we used the screwdriver like a shoe horn to slip the new shoes into place. However once they're in the jamb the pivot shoes won't move up and down. It's too tight.

Hello,Enclosed are pictures of the Pivot Lock Shoes that I have that I'm looking for replacements.I need to replace the Pivot Bar as well Product Code 26-356.I also need to replace the spiral balances as well and have identified what I need with those.I just need help in determining which Pivot Lock ... (cont.)

Can you please help me identify this part? I tried your part number 15-120 but that's not the right one.

I thought I bought he correct pivot shoe 5/8 thick. But after i replace 4 of them and tried to re hang the windows the pivot bar wont fit into the Pivot Shoe. Now i got 20 pivot shoes that wont work and a wide open window. Is there a different pivot shoe that will fit.If that little piece of plast ... (cont.)

I purchased Thermal Gard pivot shoes for a job. They are Thermal Gard windows. Your product code is 15-070. I have attached a photo of the old one next to the new one. My old one measures 1 1/4" in width, 1 13/16" in overall height, and 5/8" in depth. According to your spec sheet on the 15-070, I ... (cont.)

This is one part but you can see that its broke. The windows are 40 years old. the whole piece is missing the cam. Can you help us ?
