Viewing all customer Discussions for:

15-177 Coil Balance Shoe, Slate Blue

I have an Allianced window, picture included of the window identifier, not sure if one of those is a model#, but it is Alliance. I have included a picture of the pivot bar, since I might as well get some of these for future replacements. The real issue is the side window mechanism, picture of good ... (cont.)

I need to replace this pivot shoe. I think most of the pertinent details are in the photo: vinyl tracks, constant force, tilt sash. Unfortunately I don't have the dimensions available right now. Can you giude me to the right product line so I know what to order once I know the dimensions? ... (cont.)

model number 054-654098 window won't stay up spring broken on both sides double pane window tilt in

pivot shoe of the right bottom part of the window. Not sure of the removal so there is only the pic of the exposed part, The only info is from the side of the window. 04/17/04 PLDH-LS------33272 20.75 X 12.875---------May be you can match the window part to the pivot shoe part.

Looking to replace the entire mechanism. I was told the springs are as follows. S175BS and S175BL. I'm looking for a complete assembly if possible.

Looking for this part and the barrel and the sleeve the barrel rides on can’t find them . . It appears to be 8lbs is it the 15-177 ? Does it come complete? If not what are the 3 parts #'s. Thanks

Looking for that shoe and the balance for shoe

I am looking for the part number to replace broken slide in my alside window. I think it might be 15-177? I don't think I need to replace the coil springs. see picture attached

Allows the window to glide within the tract

Looking for the correct parts for 1.balance assembly, 2.coil support 3.pivot shoe. 4.coil balance.

Coil is 1/2" wide with the letter "E" stamped on it. I need 2 coils and 2 covers. The window weighs 11.1 lbs. Can I use the existing boot or do I need to replace that too?

Looking for replacement. Just want to verify what part it is before I order. I have ordered them before but only saved the reference number and not the part number. Thank's for the help .

The metal cam in the pivot lock shoe has broken on several of my double-hung replacement windows. The cam is 5/8" diameter (the shoe is 1.5" x 1.5%. Do you have replacement cams?

Hello, I’m hoping you can help us identify and order the correct replacement parts for several of our windows. We have about five windows where the blue shoe brackets have snapped. The part number on the blue component appears to be 5.704.165. Each side of the affected windows seems to have ... (cont.)

Hi. We really just need the bushing for this part, but would like them in heavy plastic/not white metal. 1 1/4 x 5/8 x 1 3/8, but add 1/32 to each measurement. These were soft lite windows. Thank you. Bob Need 30 of them.

Pls check to see which parts are required. I see the #8 on the spring. Hopefully, the measurements help. Pls let know is I must change out the screws or covers whatever that might be.

The tensioner seems to be working properly but the cam is sheared off. Unfortunately i do not have a manufacturer or much more information to go off of. Thank you for any help you could provide.

I need to replace 8 coil balances marked with the letter "E". They are 1/2" wide and being used in conjuction with your part numbers 15-177 and 26-316. Does the letter indicate the weight, or do I need to weigh the sash and divide by two? Thank you.

Good afternoon, I have a couple of windows with broken lock shoes. As you can see in the image, the metal broke apart. I'm just having a hard time finding the correct parts that I need. I also included a photo of one of the lock bars. I may need to replace those as well, they seem to be a little be ... (cont.)

Looking for 2 of these
