Viewing all customer Discussions for:

39-546 Truth Snap-Stud Bracket

Hi Iwant to replace windows parts But i dont know parts name and serial number Could you see my picture and how can i order it? Parts maker is TRUTH Thanks

Need replacement for part attached. Please advise. See photos . Need left side and right side

I need the piece that mounts on the sash with the pin. It measures 3" in length. Need one left and one right

i need a left and right

Need to replacement hardware for 11 inch operating else we encasement you need twin unit set up thank you Curtis Mc Kinney can be reached at 215-921-0015. Or Niblackassoc@gmail.com

Looking for a casement operator replacement. Its a right handed operator from an MI Window model 9770. Thank you

Need to replace the attached window cranks. I would like to match the style as close as possible.

Am I correct in assuming the replacement parts I need are 39-528 14 1/2" Truth casement track 39-529 Truth hardware track slider 39-546 Truth snap-stud bracket? I already have the crank. Thanks.

The only thing I have is the picture

truth operator: 05042006 09:08 Window bracket is permanently attached to the arm Thanks for your help!

I recently purchased Truth Stud Brackets (39-549 & 39-548) and Truth Operators (39-315 & 39-316), however i don't know how to connect them?

I have casement windows that have Truth hardware. The casement operator arm is attached to the window with part shown in the attached pictures. The 001 gif picture on the right shows the top view of the part. The hole in this part has a "Button" that be "PRY[ed] TO REMOVE OPERATOR". The top v ... (cont.)

Attached is the picture of the operator I am looking to replace ..I also would like a crank for it. I have just received other operators that you have recommended they fit perfectly. Thank you for your help, hopefully you can help me with this operator and crank. Thank you Cookie ... (cont.)

Part number RN 45136 the middle of the crank and arm is 5"

Hi,Need left and right for champion casement windows.They where missing when we bought the window and haven't had much help from champion.Bought it from habit for humanity restore which received it from champion when they closed showroom.The male spline size measures .350" over the teeth diameter. T ... (cont.)

This is the mechanism that turns my windows open and close. The piece doesn't spin anymore. I can barely read the numbers on there, but here goes my guess. 1491-1201 or 1491-1206 or 1491-120B

Hi we are searching for the operator bracket and hinge replacement parts for a weather shield casement windows. The number 31850 is on a part? Thanks in advance for your help. MJ

Operator ID Help and bracket

I need to replace the operator and stud bracket. I believe the Truth Hardware Dyad Operator, Product Code: 39-171 is the correct operator but I am unsure which is the correct stud bracket. The original 2004 Vetter operator has the stud bracket permanently attached to the operator arm. Apparently I c ... (cont.)

Truth window crank apparatus 45345 Extension arm 31850
