Viewing all customer Discussions for:

15-228 Pivot Shoe, 17/32" Thick

Patent #s 5,232,208. 5,365,638. 6,584,644. B2. 22 marked inside. 1/2" wide coilShoe 9/16 x 1.25" wide x 1.5 longWindow weight = 16 lbs.

The latch is on a 47" SH window. You list several. Do I need to measure the existing? Also, if you look at the picture, it shows the spring holder is above the top of the window frame which caused the latch to break. Can the window spring holder be lowered below the window top? The 2nd & 3rd p ... (cont.)

Good Afternoon. I believe I have 2 broken coils. The first pick looks the same on both sides of the window frame. The second pic is a good working window - I don't even see the coils. The third pic is when I release the balancer ? Not sure of proper names. The last pic is where I tried to pry the to ... (cont.)

Window weight is 17.6 pounds. The part does not have any numbers Need two window bouncers are left and a right for bottom window. The size of the window is 28 x 32 1/4 no name on the window.

I would like to replace everything pictured. 2 windows. I don't know the brand. Plastic coil carrier part #801020 Coil stamp #5.5 35" length Please help me choose the correct parts.

Can you please let me know what parts these are so I can order the correct parts. Picture 6970 is approx. 4 1/2 inches long. Picture 6973 looks like your part 15-228. Please confirm. Also do I need to replace the coils? Thank you.

Please see pictures, it looks like a 3/8" width double coil spring setup

I need a spring replacement the one in the photo broke and won't pull up the window. The window I believe is from American craftsman

Believe this is from an Atrium window about 10 years old. Spring has a marking that is 7.5# 35". There are some other numbers that are difficult to make out. The window weighs about 15#. The holders appear to be in working order but both springs are broken and bent. Springs are 1/2" wide. ... (cont.)

I have a window that needs that won't stay open on it's own. The right side is broken. Please help me find the parts I need. Thank you.

Hello,could you please let me know which coil replacement parts I need to order Thanks! Natalia

the coil is broken and we need to replace single hung window

Looking for a replacement part

Coil balance 5.365.638i don't know manufacturer. As you can see the channel guide doesn't have cut area for me to remove the hardware - it runs top to bottom. Do I need to cut an exit? I made a cutout to remove coil and shoe. The window weighs approximately 11lbs.

We are needing to replace this.

Can you Please help me with those parts ? number on spring is #8 thanks in advance

1 1/2 inch tall, 1 1/4 inch wide, 17/32 inch thick

Both sashes, top and bottom, have a problem with balances and what I think is the spring, or coil, that has popped out of its housing. I am the woman of the house and the designated fixer for all house problems, so was hoping to get the parts and salvage this window, You can see that one foot has b ... (cont.)

Hi thereRecently heard a pop come from our window and it stopped sliding smoothly or closing completely. I removed both windows to take a look and found this part cracked. These are in a double hung vinyl American Craftsmean Portrait Series windows. Numbers/Letters on left read: 5.Z3Z.Z06. mayb ... (cont.)

I have two windows in a rental property that need work. The first on is missing the right side hardware and the left side is pretty mangled looking. The second window is missing the right side hardware and I've shown the left side. I think it would be wise to replace all balance hardware on both ... (cont.)
