Viewing all customer Discussions for:

15-046 Pivot Shoe, 1/2" Thick

Just trying to make sure I purchase the correct one

am looking for Pivot shoe for tilt window I would like to send you a picture if I can so you might be able to match it or get closeThey are 1/2" thick by 1-1/4 wide by 1-3/4 long

The part is 2 inches by 1 1/4 inches by 1/2 inches thick. I have included a picture of the torsion bar that it fits into. The part I have is all plastic with a metal top plate where the torsion bar enters the shoe.

There's a #3 on the front but no other markings

Im trying to match this shoe. Not the typical channel shoe. Do you need to replace the whole balance assembly? You see the rusted out one in question. First time I have seen this style of shoe with a channel balance.

The picture shows a red insert, in the back . The cam is white/yellow from age. Have not found this exact match. This is on a small window, used in a bathroom. One frosted glass. I've ordered some of these before but all white which was used on a larger window.

I need a pivot shoe for my window but I dont' know the make of the window. Double Hung vinyl. House was built in 1996. Roughly te pivot show if about 5/8 deep. The only stickers I can find on the window show: 1DHSTW 247866 (ref no) 1 (line) 1 (seq) 32-1/16 x 22-5/8 Grid 3x2 I also need bottom weathe ... (cont.)

Need to replace right spiral balance on a Quik Fab 4000 (not aluminum).

It looks like 15-046 will work for my windows but I see no way to get them in the channel. Any suggestions?

I am replacing broken pivot shoes. They measure 2"x 1 1/4" and has depth of 1/2". I am replacing broken spiral balances as well. They are green tip, 3/8" wide by 39" in length. That part is easy. The pivot shoe is not. They have blue cam with black brake. I do not know the manufacturer of the window ... (cont.)

This is a tilt window. The actual metal channel is 25" long and 1/2" x 1/2" wideth & depth. The lower end of the channel connects to the tilt lock and the top end has a string coming out that connects to a screw in the side of the window, up high. I do Handyman tasks in a fairly large communit ... (cont.)

The slot in these shoes is molded in vinyl, which has embrittled I will probably need to consider new balances at the same time for these windows.

I need to find window balances to match ones in the attached photos. Total length of the balance is 28.5"

Hi. I have a Crystal 2000A double hung window (see label) and one of these white plastic inserts that hold both the window and the ballast spring snapped and broke at the top so that it can't hold the ballast. (Sorry about the crud. Didn't think to clean it.) This picture is of the other side that's ... (cont.)

Hello, I’ve attached a picture of a part that I’m looking for and the dimensions. If you have it, what’s the price? I’m looking for a few. Thanks! Height =2 1/8 Width =1 1/4. Depth =1/2 inch. Thanks!

window parts

Trying to find window parts for windows installed in 2000 by builder. Balances, Shoes, and Pins.

Pivot shoe is broken

About 2 3/16" tall. About 1/2" wide and thickness as shown. Thanks for any info, Patrick

need to replace one broken pin, and how to install
