Viewing all customer Discussions for:

39-026 Awning Window Crank Operator

Take a look at our 39-025 and 39-026 operators, compare the dimensions between our parts and the parts you are looking to replace, and see if these operators will work for you.

I need to replace the crank handles on 5 of my jalousie windows on my back porch. I also nee to replace 4 panes of glass that have moisture in them. I cannot find the name of the he windows any where on them. The windows were here when we bought the house so I think they are about 20 years old. Do ... (cont.)

Can you tell us what the distance between screw holes is, from top to bottom? This will allow our parts experts to better recommend replacement options.

Take a look at our 39-060 operator, compare the dimensions of your operator to the picture below, and see if this part will work for you. If the dimensions do not match, please submit your dimensions and we will do our best to find you a replacement option.

Order # 1175997 I cannot connect extendor arm to window . Did I order the correct replacement ? 39-278 Thank You

Hi, Can you please let me know if you have or can get us this part? It is an awning operator. I attached some pics, and below are the details I have. Type II Housing - 1 top hole, 2 bottom holes w/ offset Dimension A - 5-1/4 Dimension B- 1 1/8 Dimension C - n/a Dimension D - 2-11/16 OS Link/Arm ... (cont.)

Pat.No 198202 US this is the only number on it. In case you cna't read the numbers written on the paper in the pictures the height is 5 1/4 distance between screws on bottom: 1 1/8 ctr to ctr arm bar is flat and ctr to ctr is 2 1/2

I just bought a house full of awning windows. Several have stripped handles. I think your site might have the right size. Could you please look at these photos and tell me if the 39-025 and 026 are the right ones? If so I might start with two of each (in bronze) to make sure they will work. I?m not ... (cont.)

I am looking for an awning window crank operator which is like your product code 39-026 except the arm extension is 2 & 1/2" and is held on with an E clip. The size is from hole to hole, but there is no hole, it's a peg with a E clip. see the attached pictures.

The subject operator is depicted in the attached photos with the handle removed and sitting beside it on the windowsill. These are awning style windows from a house built in Broward Count, Florida in 1968. I noticed the window was slightly ajar and when I went to close it, the screw mechanism that t ... (cont.)

Can you supply this operator? May need several each right & left. Vertical hole spacing 5-1/4", horizontal 1-1/8", end link is 2-3/16" c-c w/10-24 stud, uses screw with shouldered plastic bushing, bushing OD 3/8". Main gear arm is 2-5/8" c-c, end link is flat. Prefer white housing. Could probab ... (cont.)

These are markings on the operator and the operator handle on the inside.Letters and numbers are:WYNN 63.5LAI can't find these anywhere. Not in any hardware store ,not even in Home Depot.Please help.Thank you, William O

I need to Replac an operator need to know what model number it is.

We need to replace the window crank mechanism for an old awning window in our bathroom. See attached pictures. No name on window. number on crank handle is 11-100-11 patent pending. Patent number inside mechanism is 198202US 2RHRD 1963 CAN. Also the arm extension is 5 1/2" inches and has a 'grommet' ... (cont.)

I purchased the Keller window crank, 39-060.The 3 mounting screws are OK but the original oprerator has a bushing instead of a flat arm and also has a plastic sleeve over it. I would like to know if you have the exact part or I should purchase something different.

I need to replace these operators. Can you help?

I have this window crank that broke on the window. The window is very old. Anyone with tips or possible part numbers would greatly be appreciated.

Need replacement window crank for jalousie windows. Jalousie window crank needed. Mounting holes about 5 1/4" apart.

I thought I was all set to buy an operator from you, but I see that the arm length on center on my unit is 2-1/2". The best I can tell, all your lengths are shorter. I measured from center hole to center of rivet.

I attached some pictures with measurements of my existing operators. Several have stripped/broken and need to be replaced. The windows are about 16 years old and I don't see any manufacturer tags which makes finding a replacement operator that much harder. Looking for several LH and RH operators, ... (cont.)
