Viewing all customer Discussions for:

15-047 Pivot Shoe, 5/8" Thick

don't know the depth of the shoe, hoping you can ID the right part.

I need to replace few pivot boots for windows in my home. I measured the depth and it is between 1/4" and 5/8". It is surely not 5/8",more like 9/16". Looks like I should go for 15-046, which is 1/4", rather than 15-047, which may not go into that slot. Just wanted to confirm that is the right choic ... (cont.)

2 inch high by 1-1/8" width depth is 5/8" Do you have anything that is compatible to this?

Hello,I have these blocks to hold the window open and the one on the left side of the window is broken. Please let me know if the dimensions sent on the last two photos are enough to identify the part. Thank you,Fernando

How do I get the parts AND shoes

looking for a replacement pivet shoe. Mine is about 1 1/4 inches wide, 3/8 inches thick and is about 2 1/4 inches long. This is a replacement part for a window made in 1996. It is a tilt window with a spiral balance. Please let me know if you have or knows some organization that has them. ... (cont.)

Hello, Can you help me identify which window shoe I need? Attached, please find three pictures, two of the shoe and one of the pivot bar. The dimensions of the shoe are identical to two parts I found on your site, 15-070 and 15-047. But, the pivot bar doesn't seem to match either of the pivot ba ... (cont.)

7 of nine windows in my house have broken shoes and looking to replace all shoes. Hopefully the plastic is better with new ones the old ones became brittle and broke. Here are the picture of the shoes hope you guys can help.

Some sliding/tilting windows in my coop apartment had their pivot shoes break, and I need to replace all 4. They are regular spring loaded, not spiral, from what I can tell. I can't quite decide between the 9/16" and 5/8": what I measured looks like the thickness is kind of in between. So I would l ... (cont.)

I am looking to purchase replacement window parts for our condominium. Pivot Lock Shoe Black Cam 16H98, 1-1/4 x ¾Tilt Balance ToolCaldwell Balances Attached is a sketch showing the sizes of various windows. Also provided are photographs.

Hi, I need a the seat at the end of the balancer and the post that is attached to the window that goes in to the seat. Thank you, Sarah

What is the significance to the color of the cam if any? This shoe is black but I?ve seem blue, red, white etc. on your site. Thanks.

Trying to repair a few broken vinyl Windows and I would like to replace these

Hello, can you help me figure out what part I need to replace this? Thank you, Courtney

Pls help me for right parts Tkx

Sirs: Do you have a replacement for this type of pivot block? Thanks, Eric

I have windows which seem to have had the spiral balances replaced with the wrong size. Can I measure the window run (almost all the way up minus spacer) to all the way down to figure the spiral balance size (length).The windows are double hung vinyl tilt-out, the shoe is 15-047. I also need to repl ... (cont.)

Hey there - Happy Friday to you! I need to replace a couple of pivot shoes that have broken in windows in my house. Pretty sure these are either 15-047 or 15-046 pivot shoes. They look more like the 15-047 with the black part, but the thickness really seems to be 1/2" like 15-046. If worse co ... (cont.)

looking to buy 12 of these with spiral balances do you carry this shoe
