Viewing all customer Discussions for:

15-180 Coil Balance Shoe

I have some pictures to identify

I am looking for a replacement double coil balance spring for a single hung vinyl window. There are no markings on the window itself or the spring. Todd

Hi Again..., Yesterday we discovered that our tenant damaged the vertical sliding mechanisms in two (identical) double hung window. We think she forced the upper sash down, breaking the balance shoe and the support clip. I've looked thru your site and think I've figured out the components needed to ... (cont.)

I need to find the coil support for this window. When i tilted the wind i seen that the coil support was broken.

I need this pivot shoe brake. It measure about 2.125" long (I did not remove a good one for exact measurement) The width is 1.250" and it 9/16" thick plus the 2 little nubs sticking out making a total thickness of 21/32".I think the windows are MICHIGAN WINDOWS, obviously double hung, vinyl replacem ... (cont.)

See picture for description dimensions and weight of sash. No numbers but found warranty page in documentation. Not sure if that's the same window. I need a new coil spring assembly for the left side facing out. Please provide the right part number for the replacement. Thank you,Terry ... (cont.)

Please provide price for the coils and hardware shown. I want to replace the coils and hardware for two windows both left and right sides

Needing 20 pound window shoes as pictured. Please let me know if you have. Probably need at least 4 of them. No names or numbers seen.

h-r40 on the label for a 34inch x 60inch single hung window Need both sides for multiple windows

does this part number accept a screw 2" in from the exposed end?T Bar PivotProduct Code: 26-45Picture of pivot pin , need 8Also need 4 balance assembly

Hello,I was hoping you could help me determine replacement parts for my window. I would like to replace all the hardware, not just the spring. I need them for both sides of the window please. The window is 14 lbs. I have included pictures of the broken part and the peg on the window. Let me know if ... (cont.)

Hi, I need help in finding replacements for the attached photo of coil parts for two windows. Both windows have broken balance and will not stay open. Thanks, Jessica

Our balancer coils snapped in 3 of our windows and I need to replace all of the parts that are involved. I've included photos of the parts and I'm hoping you can tell me what parts I should order. Thank you in advance for your help.Eric

Hi, I have multiple windows which need their balances replaced. I haven't looked at all of them, but I will probably need 6 pairs. My window sashes weigh about 19 pounds. How can I determine if your hardware (for example https://www.swisco.com/10-lb-Single/pd/Series-140-Quick-Tilt-Balance/S140-10 ... (cont.)

Looking for the part number for the attached picture. Thank you in advance.

need help identifying these coil balances

Hello, I am looking for the window coil balance in the photos. The only information about the windows I can find is that of the Quality Control & Testing AAMA Certification Program, Series: 3500, AAMA/NWWDA 101/I.S. 2-97, H-R20-48x78 H-R35*-36x66. And warranty information: MI Windows & Doors 1 ... (cont.)

Hi there, could you please help me figure out what's the replacement part for my 20X31" (13 lbs) Both sides are broken, and I need to replace them. Thanks, Pablo Ps. I added a quarter coin for size reference.

HelloI'm looking to replace the sash tension assembly on the left side of a hung window. I could not identify the manufacturer, but believe the "pros from Dover" i.e. SWISCO staff, can help to identify the replacement part :-)Thank you very much for your time and support!John

Attached find pictures of a double hung window with Coil Balance Springs. This is one of the top Coil Balance Springs which broke. The Springs are numbered 7, the Double Detent Clip is broke on the top this can be seen in the pictures as you can see both of the springs broke and need to be replaced. ... (cont.)
