Viewing all customer Discussions for:

26-089 Pivot Bar, 3"

We need the bottom swivel and also the windows don't stay up

Tilt out window by Alcoa Need to replace the bottom part somehow.

Tension springs hinge parts

Hi. I recently dropped a vinyl tilt window sash and broke a corner. (This happened while installing replacement spiral balances and pivot shoes.) I'm hoping that the attached photos will give you enough information to identify the replacement corner part(s) I need in order for us to complete the rep ... (cont.)

As you can see I need a multitude of parts. 6 tilt pins. 4 left tilt lock/releases. 4 right tilt lock/releases. 2 single spring balance/shoe assemblies (blue). 4 double spring assemblies (blue). DBA StoneRidge Construction. I've installed replacement windows, mostly Alside, for over 30 years. 100's ... (cont.)

My windows are Polaris tilt in Windows. Installed 1995. This connects the window into the inside of the window jamb. Now it broke off and the top window comes out of the window frame. Thank you.

The pivot bar measures 2 7/8 inches overall length 5/16 of an inch wide inch and 7/16 to the first hole and 2 3/16 to the second hole. The windows are 36 inches wide by 36 inches tall and manufactured by soft lite window company. The coil housing has a number on it that says 6R. It also has a paten ... (cont.)

looking for a pivot bar to replace the one pictured above

I have Phillip windows single hung I ordered #26-378 3" did not work can you tell me what will?

Please identify the part in the photo and advise of cost. If available, prefer stainless.Thanks,Jim

Hello Swisco, I will be ordering American Craftsman parts for my windows and door slider 6' can You tell me the correct slidder wheels forthe 6' American Craftsman Slidders? I will be ordering also American Craftsman Double hung parts Pivot pins, Coil Balance Springs 16.7lbs window weight and Ti ... (cont.)

2 inch long 5/16 wide 3/16 high (not rounded has a flat top)

am in need of a replacement pivot bar for my Paradigm double hung window serial #W409127-1. Attached is a couple of pictures. Mine measures 1-11/16". Mine also has a couple of protrusions on the flat side.

pivot shoe measures 2" tall, 1.25" wide, and 0.5" deep which item will replace these?

Please help me find parts that will work for this window and provide pricing. my mistake the diameter of the rod is .560 inch and is out of round. thank you

Can you recommend a replacement for this pivot bar?

used to hold window that slides I can cut to length and drill the holes 1/4" wide X 3"long X 3/16" deep metal is about 1/16" thick

It holds window into frame

I have windows with an internal tilt latch where many of the actuators are failing and need replacement. I tried part #26-234 and it's not correct. I also have a rusted out pívot bar that I can't remove from the internal holder. I'm wondering if you have the replacement holder. I already bought repl ... (cont.)

Trying to figure out replacement. Pivot bar u shaped, 2 1/4" long.
