Viewing all customer Discussions for:

15-045 Pivot Shoe, 3/8" Thick

The Pivot Shoe is about 1 inch x 2 inch x 3/8 inch as W x L x H. The Spiral Balance is 38 and 3/8 inches long and its diameter is 3/8 inches.

I have two windows that need the spiral balancers and pivot shoes replaced. On one the balancers are 17" in length and have a white tip. On the other the balancers are 29" in length and have a black tip (bigger window). On both sets the tube is white plastic and is actually a hair larger than 3/ ... (cont.)

The spiral tilt window balance is a 17 inch length and 3/8 diameter. I found them on your website as S900-17. So far so good. When I took a look at the pivot shoe, it looks as shown in the picture but very different from the recommended 15-045. The one in the window is 2.5 inches in length. Ple ... (cont.)

No luck so far I have naught 2 different ones from you please help

Hi, my name is Dan and I believe that I have finally found a company that has a solution to my vinyl poly-tex tilt window problem. It appears that I need 36 15-046 pivot lock shoes (according to the dimensions) for a total of 9 windows with a balance charging tool. I am submitting a photo of existi ... (cont.)

I'm looking for balancers for my Better Bilt tilt windows. The house was built in 1996. I believe the tube is 3/8". I have 4 windows that either do not stay open or open. If you need more info I will try to get it. Thanks so much Fran

Need help identifying and finding parts. Also if found, how to remove and install new parts. If parts can't be found, is there an after market fix that I can try.

This was removed from a customer's window to identify the parts needed to hold window up. Can you tell from these pics which one it could be? The sizes are 1"×13/4" with a thickness of 3/8". Any help would be appreciated. We will need to order balancers too after identifying this part. ... (cont.)

unknown manuf. no identifiable markings tilt latch is 2 1/4 X 3/4 X 3/8 thick (not including latch point) pivot shoe is 1 7/8 X 1 (actually 15/16)X 7/16 thick at widest (top part) note: spiral tube is 3/8" dia (works ok)

Hi Swisscom customer service ,I am trying to replace failing spiral balances and pivot shoes alum insulated windows in a townhome(built ~2004). Bottom sash tilts and 2 window sizes are (A)~34.5" wide x 35.25" H(B)~46.5" wide x 32.25" HBalances currently installed are 3/8" dia w/ white plastic covers ... (cont.)

Do you carry this attached lower window balance cam? Have attached bar and loaded female end. I need the pot metal bar only.

These are for CareFree brand windows. The tip is red, the length is 29 inches, and the diameter is 3/8 inch. It has "ET A" on the side of the tube.

Hi I bought 8 of the 15-045 but the cam opening for the pivot bar was too small. The installed pivot shoe is approximately 31/32 in wide. 3/8 thick and slightly less than 2 in long (about 1 15/16). See the attached photos. The cam opening seems to be like the 15-212 (5/16 X 3/16) The slot in th ... (cont.)

Thanks for writing in. I believe you're showing us glazing bead. If so, start by looking at our 55-180. Go over the dimensions of the bead's end profile and let us know if you think it's a match. For your pivot shoe, see our 15-045. Let us know what you think.

I am guessing this is a shoe for a window spring on a Carefree Window. Length of spring tube: 27 inches Diameter of spring tube: 3/8 inch Tip color of spring is orange with 2 cross prongs.

The balance is round in form and measures total length of 30 1/2 inches and about 7/16 inch wide. The part that goes in the channel is 1 inch wide and 2 inches in length. The piece that releases the window on top of the sash is 2 3/4 inches in length and 1 inch wide. The metal pieces at the bottom i ... (cont.)

I'll be happy to send more pics. Looking for two new springs (window balance) and plastic hardware keeper for left and right side. I measured and got 33 3/4 " spring. These are for a tilt window. Thank you

The shoe measures 1 1/4 wide 2" tall and 3/8 thick. The pivot bar that goes with it is one screw 2" long 5/16 wide by 3/16 I found the bar but can't seem to find the shoe on your site. Please help Michael.

Need parts: It is a tilt single hung window. I could not find any technical information in the window. Thanks.

Green tip. 3/8" diameter. Pivot shoe appears to be 15-045. All 3 measurements are exact.
