Viewing all customer Discussions for:

16-024 Mounting Bracket

How do I know what weight coil to order? On the end mine are etched 7 CB ( mine are broken ) my original widths are a half inch wide with 2 holes on the end. Looking at your site I would guess I need part 15-087 Coil housing pivot shoe and the series 180 coil balance. Please confirm on both of my a ... (cont.)

Please refer to cavity dimensions to help with selection of devise that may work in our situation. t Thanks , Bill

Had 2 coil balances break on an Anderson window today.It looks like the coils are stamped 5 BD or DD and they measure 15/16" wide.The sash weighs 20 pounds 8 ounces.They look like your series 180 coil balances.Would the 5 pound be the correct one?Would the 15-086 tandem coil housing and the 15-087 c ... (cont.)

thanks and finally i need this piece that attached to the other end of the spring.i think this is the right mounting bracket.https://www.swisco.com/Mounting-Bracket/pd/Sash-Support-Coil-Balance-Accessories/16-024

the only numbers i could find were the following: 1257801 52-8506-wht

I need a replacement balancer and tilt bar with plastic housing. The bar has sheared due to rust and I?m unable to remove it from the shoe.

First two photos are located on the right side of the window and are the broken parts. The third photo is located on the left side of the window is in good condition, and Not Broken. The actual size of the good part is 7 inches height, by 1 inch width. The window itself would not slide up due t ... (cont.)

the window is 44 pounds, vinyl frame. the existing balances appear to be 35/64" deep by 1- 17/64" wide with 3 coils. I inadvertently damaged them while installing the window. Have been unable to contact Crestline. I need 2 pair, plus do you have a spreader tool to remove/install them? Thank you, ... (cont.)

I need the coil window spring balance with 1/2 high 2 1/2 my # 917

looking for spring pivot shoe.

I need qty 2 of the part in the attachment.

I need a sash lock and balances for some Gorell windows. The Gorell model # is 5155 and measures 23X59. Please see attached photos.

Hi I am trying to replace the pictured part. It has a coil on top and a shoe at that bottom. I think it is all one part. It holds a heavy double hung tilt window up. There was only one coil when I removed. Can you help identify and suggest a replacement part?

Please help me locate this part.Pat5,353,548 stamped on side.Two of the tandem housings are marked 7 and end housing is marked 8.I need the coil springs also

Our 15-year old double hung upper channel balance ENDS look like this? And windows are very loose in frame--easy to jimmy window locks to open from outside. Is this really the right part? It's screwed in barely half-way up the upper window. Need proper parts so I can secure our dozen windows. S ... (cont.)

Attached are the parts of double hung window manufactured by survivor window

I have a number of windows (new in 2009) that have the constant force balance that consists of 16-024, 15-087, and S180-7. When the sash is tilted, it doesn't stay locked at the pivot point, but rises up without any resistance other than the weight of the sash. Essentially, it takes two people to ha ... (cont.)

The spring on the left side of the sash is broken

How do u get both springs to hook on to the screw bracket that anchors them? The significant amount of tension in the coil springs appears to make that somewhat difficult? Please explain?

how do you go about removing the old balancer out and installing the new one is there a video on youtube that demonstrates this please get back to me with the information thank you. Louis Gillingham
