Viewing all customer Discussions for:

S180-04 4 lbs Series 180 Coil Balance

Hi I need this pivot shoes cover which is cracked. It had two 4 lb constant force balances in it. If this is not available can I replace it with a single 8 lb pivot shoe. Thank you. Renzo

I am trying to figure out what balance coil I need. It has two springs/coils in each one. I don't know how to remove them. Do I need to notch the window frame as in a U tube video?Sorry there is no name on the window. Help!

I am looking for several window coil balances (right and left) for a 17.8 lb. window. Thank you,Billy

Hello here is a photo of one of the two constant force springs that i need (left and right) the bottom window weight is 17.5 LBS the numbers on the springs are 5.15x and 4.16x i hope this can help in identifying the correct parts Thank You Marc,

Need parts for both sides and price

This is what came out of my window sash. Note the upper housing has a piece missing from it. Looks like the bottom is 4lb and the top is 5lb, there were numbers on the springs that did correspond with the casings. Can the whole things be replaced, they look pretty worn and cracked, and what would th ... (cont.)

Hello I need a coil for an ideal window. Mine snapped after about 11 years. The Balance shoe says (4R ). THE COIL SAYS 4AEPlease see attached pictures for more details of the model number. I see that most of your coils only have one ( hole ) mine has two holes as you can see. but I think the one wh ... (cont.)

Tim:1st photo American Craftsman 16 lb sash; 2nd photo American Crafstman 22 lb sash; need both sides left & right for bottom windows. 3rd & 4th Photos are one DACO window 16 lb sash; need both sides upper window length of spiral lift is 22".Thanks. Be Blessed.Pat

I am not sure what the numbers on the spring mean? I need to buy a few of those springs for my window repair. Just like to be sure. Can you please let me know? Thanks Jack

I ordered the S210-14 and it looked pretty close to the one I had bought the thickness on the old one is 9/16 ,the S210-14 is thicker. The 1st photo is just half of the way it should look ,if you can see the second photo shows two together and each one has a 7 imprint. The springs thickness is shy o ... (cont.)

We need to replace two traco quick tilt constant force balances. I took pictures of how it looks now. The window is Traco. Maybe you can help me by looking at the pictures. And what really needs answered is how do we take out the old balances out without ruining the window? To me it looks like a ... (cont.)

I have a window that was purchased 15 years ago. I need to replace the tape balances. The manufacturer at the time was Optimum. They are no longer in business. The size of the balance shoe is 9/16 d x 1/14 wide and 1/12 high including tabs on top. The sash weight is 8lbs. The sash size is 18 .5 " hi ... (cont.)

I need 2 ,one for each side what looks to be 15-086 and 15-807 pivot shoe or maybe tandom coil housing the window (lower ) weigh 18 pounds, S180-8 for springs ? . Also need 2 16-024 mounting bracket and 2 of the top locks that measure 11/16 wide x 1 5/8 long. pat number on the window pivots are 5353 ... (cont.)

Can you tell me what part I need to buy? The window coil has come off the part and no longer slides. The Part number is 5,353,543 Please see photos

Not sure what to order. Need bottom left & right parts.spring only part marked with a 4.Hope u can be a help.

Wanted to find out how many pounds of the coil balance. Sash is about 21x21 inchesThe original coil spring has "4BC" stamped on it

I need two of these to replace the ones in the picture. Please let me know what i need to order thanks.

pat.5,353,548i have these constant force balances throughout my house. many of them snap up when you take sash out for cleaning. i measured the square footage of the bottom sash. i have ten windows, and i came up with 3 weights. 6 bottom sash weigh 21.4 lbs. 2 sash weigh 18.2 lbs.2 sash weigh 15 lbs ... (cont.)

I need to replace the single hung spring coil fixture for two single hung windows. I don't have the manufacture's name or the part number. I do have the patent number found on the spring coil housing. Patent: 5353548 and two photos showing the casing on both sides. Each window has two spring coi ... (cont.)

I need balance shoes as above, almost 9/16 (35/64?) x 1 1/4 x 2 7/16. Windows weigh 8 lb, are 19 1/2" and 20 1/2". When I order, I will need 4 shoes; 4 anchors, since I am not sure of the condition of the anchors; and pivot bars if the new balance shoes don't have the same slot as the old shoes. ... (cont.)
