Viewing all customer Discussions for:

33-070 5/16" Shoulder Screw, 1/4"-20 Thread

1717r inside part

Hello, I have a 1950s house with Keller awning windows. I am in need of replacement operators. The measurements are 5-1/4" top screw to bottom screw with a 2-3/4" arm extension. This is the old one and I saw somewhere on your site that the screw hole size in the link arm is important. I believe ... (cont.)

Trying to identify the replacement part for the crank mechanism on a jalousie window. The crank comes off when you close the window.

Pix 1+2 show broken off sissor hinge openers on North unit installed late 1970's 3rd pix shows intact unit which has scissor hinges as photoed on both sides of over n under glazings

How does the arm of the crank attach to the hole in the arm of the window? Is it a threaded bushing with a screw?

I can get the window to open but I can not get it to close. The handle comes out of the operator.

LEMCO SERIES 30Will you need photos of the inside of the current broken crank to determine what model I need to buy

Looking for replacement aperator

This is the part that is on the side of every window pane frame that projects from the edge of the frame that when you close the window sits under the claw in the mechanism and locks the window as the crank is turned and draws the window up and in.

I need this ASAP. I have sold my house and this repair is on my inspection list

I just received my RH Awning Operator (3/8" hole, Part # 39-419). With it there are several parts to link its arm to the arm of the awning window, including a 5/16" Shoulder Crew, 1/4" - 20 Thread (Part # 33-070). Also included is a #10 X 1/2" Pan Head Phillips Screw (Part # 33-081). What I need ar ... (cont.)

Need a new operator for this really old awning window. Top to bottom mounting hole distance 5 1/4" bottom holes distance 1 1/2" Operating lever 2 1/2 " center pivot holes. 2 pictures attached

Markings inside read 3RH 18-0821

Awning window parts The swingarm has a measurement of 2&5/16". All other measurements are the same as part number 39-350. I need three left hand and two right hand actuators. I also need three shoulder screws 33-070 torque bar bearings 36-018H. Thank you William

the measurements all seem to match. question about the 3/8 hole- mine is threaded to accept threads on bolt/screw. Are there threads in that hole? if not I possible could do a work around or less you have the exact match.

I need replacement screws and bushings for a jalousie crank out window, pictures attached. I can't find a manufacturer name on the jalousie windows, but the other windows in the house are harcar.

I have ordered 33-070 and it is too short and wide, then 33-108 which is the right length but too narrow. This is for an assembly to replace a Mepla 600.010.08.25 wall spacer for sliding drawer shelf. I will try to fix using the 32-339 drawer slide spacer. I also need some flat head Phillips scre ... (cont.)

Hello,WE'd be happy to help but it's tough for us to narrow down your replacement options without seeing the arms that move the window. We'd have a much better chance of finding the correct replacement for you if you could show us a picture of the operator removed form the window with a clear view o ... (cont.)

Looking for pins or rivets for old style casement windows hingesi only need 4 pins or rivets I ground the tops off so I could remove windows to replace glass thinking it would be easy to replace the hinge hardware. But not so easy. The rivets must be installed at the factory when making the windows ... (cont.)

I need a replacement operator that will last. The ones that I am buying from home Depot don't fit right and they don't last. The picture of the brown operator is an original one that is more than 10 years old and still works great. I need a replacement like that one. Also, I need oversized screws. ... (cont.)
