Viewing all customer Discussions for:

75-006 Spiral Balance Charging Tool for Tilt Windows

We believe the window is a Care Free Window. Our house is a Dutch Housing, Inc. manufactured home built is 1991. It is a 53 x 46 inch window, the tilt part weighs 21.2 lbs., 25 3/4" long and 3/8 diameter.

I Need 2 Pivot Shoes(picture attached has code: 530C). Not sure on depth? I think its 1/2 inch but hard to measure without taking it out. Can you confirm with this code? Also, need 2 spiral balances (picture attached)(red) (appears to be the 5/8") 21 inch long. Maybe the spiral balance too ... (cont.)

Instead of fixing the top sash spiral balances, I'm looking to fix the top sash in place. I believe the window is a Traco Tr5000. Is there a bracket or clip that I can attach under the pivot shoe in the track and screw into? This is a picture of the pivot shoe.

Hello, It looks like our window needs a replacement spring kit. The first two pictures are the brand of the window; I called Haddonfield Lumber and they recommended me to you. The window dimensions are 32X54. The window automatically falls when opened (we keep it locked to keep shut) because the pi ... (cont.)

I need 4 spiral balances for traco double hung tilt in windows. They measure 41". Hope you can help!

Pivot shoe. Not sure about thickness. 2" H. 1 1/4" Width Pivot bar 3"

This piece broke on the other side of this window.

I need pivot shoes and post. I've attached photos. Shoe size is 9/16 thick " tall 1 3/16" wise. Pivot bar is 3 1/8" long with a round head that is 3/8" wide

Please help identify what replacement shoe I need for the one pictured. Spiral balance tilting window 29" length red top

21 inch tubes 1/2 Inch Tabs Red tip Would it make a difference if I replaced red tip with black tip balances I also the tabs that the metal spring connects to. What do you suggest?

Koolvent glass FDH window Need a replacement pivot lock. 1/2" thick fits on the end of a 25" spiral balance Part is 1" wide and 2 1/8" long

good afternoon, my windows are 24 years old and i need to replace a broken balance shoe. its 3/8 by 1 1/4,but i can't seem to find a replacement for it. can i use a 3/8 by 1" ? thanks for your help.

I have a couple Alcoa vinyl tilt windows i would like to try to repair the info i have came from 35.5 X 59.5 inch window #91018600.11, mfg 01/05/94 in sprinfield ohio, style 2V1H6L, All windows installed on new house in 1994. The window with the broken spiral balance is 23.5 x 72 i think. It measure ... (cont.)

in need of these slides for plygem single hung windows bought from home depot about 15 years ago. Also need the spring apparatuses that attach to these if available. let me know thx

when the window would not stay open I took it out of the frame and noticed that the plastic part at the side was missing. There is a small pin (size of a screw) that sticks out and fits into a hole in the inside portion of the window which is attached to a spiral piece that expands and retracts as y ... (cont.)

Firstly I would like to complement you on your site. It's a joy to use. I am cursed with home center stock vinyl tilt single hungs that were in the house when i bought it. I nearly herniated myself trying to open them so I've removed the operating sashes, cleaned everything, adjusted the spiral b ... (cont.)

Hi. I need to replace some broken pivot shoes. Pic 1 is of working shoe, pic 2 is of broken shoe in the channel, pic 3 is of the shoe removed. It obviously missing little metal claws that catch the spiral. The shoe is 1/2" thick, 1 1/4" wide, 2 1/8" high. They work with 1/2" diameter spiral ba ... (cont.)

i emailed you this am here are my pics of you get them i need 4 pf each

Do you know what part number? and the measurements are 1/2 D x 1 1/4 W x 2 inch L and the spiral tilt window balance is 9/16 Blue x 17 inches [need part # also], Thanks I used to bring my windows and screens to you in Camden Thanks Sean

The pivot shoe is 5/8? deep. The springs are around 30?. I think you can see the other dimensions in my photos. Hope you can help us. Pat
